Horizontal packaging machine is mainly used for biscuits, cakes, hardware, and other products that need independent packaging. It is a semi-automatic manual feeding machine. It is economical and easy to operate. It is very popular in production plants.

  • Dual transducers control and bag length can be let and cut in one step.
  • High-sensitivity electrical eye traces and sealing position is input numerically for accuracy.
  • Positioned stop function without sticking knife and wasting film.
  • AII control is realized through software. easy for adjusting and technical upgrading.
  • Simple driving system, reliable working, convenient maintenance.

Parameter

SK-W250

Packaging Film Width 250mm
Bag Style Pillow bag
Bag Length 65-190mm or 120-280mm
Bag Width 30-110mm
Max Outer Diameter of Coil Max.320mm
Packing Speed 40-230bags / min
Packaging Film Thickness  0.04-0.08mm
Power Specifications 220V, 50Hz / 60Hz, 2.6kW
Product Height Max.40mm

SK-W320

Packaging Film Width 320mm
Bag Style Pillow bag
Bag Length 65-190mm or 120-280mm
Bag Width 50-160mm
Max Outer Diameter of Coil Max.320mm
Packing Speed 40-230bags / min
Packaging Film Thickness  0.04-0.08mm
Power Specifications 220V, 50Hz / 60Hz, 2.6kW
Product Height Max.55mm

SK-W350

Packaging Film Width 350mm
Bag Style Pillow bag
Bag Length 65-190mm or 120-280mm
Bag Width 50-160mm
Max Outer Diameter of Coil Max.320mm
Packing Speed 40-230bags / min
Packaging Film Thickness  0.04-0.08mm
Power Specifications 220V, 50Hz / 60Hz, 2.8kW
Product Height Max.60mm

SK-W450

Packaging Film Width 450mm
Bag Style Pillow bag
Bag Length 180-450mm
Bag Width 50-180mm
Max Outer Diameter of Coil Max.320mm
Packing Speed 30-180bags / min
Packaging Film Thickness  0.04-0.08mm
Power Specifications 220V ,50Hz / 60Hz, 2.8kW
Product Height Max.70mm

SK-W600

Packaging Film Width 600mm
Bag Style Pillow bag
Bag Length 180-450mm
Bag Width 90-220mm
Max Outer Diameter of Coil Max.320mm
Packing Speed 30-150bags / min
Packaging Film Thickness  0.04-0.08mm
Power Specifications 220V, 50Hz / 60Hz, 2.8kW
Product Height Max.80mm

Application

SK-W250/SK-W320/SK-W350

Packaging Format Range Adjustment Method Packing Way Packing Speed Range Special Process
Baking Single product packages Display control Back seal 40-230bags / min Filling nitrogen
Vegetables Multiple packages Display control Back seal 40-230bags / min Three servo control
Plastic Multiple packages Display control Back seal 40-230bags / min None
Candy Single product packages Display control Back seal 40-230bags / min Needing  vibrating plate
Hardware Single product packages Display control Back seal 40-231bags / min None
Frozen Multiple packages Display control Back seal 40-230bags / min With tray

SK-W450

Packaging Format Range Adjustment Method Packing Way Packing Speed Range Special Process
Baking Single product packages Display control Back seal 30-180bags / min Filling nitrogen
Vegetables Multiple packages Display control Back seal 30-180bags / min Three servo control
Plastic Multiple packages Display control Back seal 30-180bags / min None
Candy Single product packages Display control Back seal 30-180bags / min Needing  vibrating plate
Hardware Single product packages Display control Back seal 40-231bags / min None
Frozen Multiple packages Display control Back seal 30-180bags / min With tray

SK-W600

Packaging Format Range Adjustment Method Packing Way Packing Speed Range Special Process
Baking Single product packages Display control Back seal 30-150bags / min Filling nitrogen
Vegetables Multiple packages Display control Back seal 30-150bags / min Three servo control
Plastic Multiple packages Display control Back seal 30-150bags / min None
Candy Single product packages Display control Back seal 30-150bags / min Needing  vibrating plate
Frozen Multiple packages Display control Back seal 30-150bags / min With tray
Hardware Single product packages Display control Back seal 40-231bags / min None
