Automatic Granule & Powder Packaging Machine

Automatic granule & powder packaging machine replaces traditional manual packaging, realizes the automation of enterprise product packaging production, improves enterprise production efficiency, and greatly reduces product cost.

The machine has a wide range of packaging. According to different packaging materials, different filling devices can be selected, and various solid materials, liquids, sauces, powders, granules, and other materials can be packaged.
Extensive packing bag range, suitable for multilayer compound plastic prefabrication bags and paper bags, low loss, and good sealing quality.
Adopts PLC with touch screen control system, the man-machine interface, easy to learn and operate.
Quick and easy to change packing size, the width of the automatic given bag device is easy to adjust by the handle.
The finished packaging bag has perfect pattern, good sealing quality, and high grade.

ADD TO CART

Product Details

Parameter

SK-G200

Mechanical Station	Eight stations
Types of Packaging Bags	Stand-up bags, handbags, four-side sealing bags, three-side sealing bags, paper bags and other composite bags
Bag Size	W: 80-210mm L: 100-400mm
Packing Weight	10-2500g
Packing Speed	25-60 bags / min (the speed is determined by the feeding material itself and the filling weight)
Mechanical Weight	1400kg
Power Specifications	380V three-phase 50HZ / 60HZ
Total Power	2.5KW
Compressed Air Consumption	0.6m3 / min (provided by the user)

SK-G260

Mechanical Station	Eight stations
Types of Packaging Bags	Stand-up bags, handbags, four-side sealing bags, three-side sealing bags, paper bags and other composite bags
Bag Size	W: 130-260mm L: 100-400mm
Packing Weight	10-2500g
Packing Speed	25-50 bags / min (the speed is determined by the feeding material itself and the filling weight)
Mechanical Weight	1500kg
Power Specifications	380V three-phase 50HZ / 60HZ
Total Power	2.5KW
Compressed Air Consumption	0.6 m3 / min (provided by the user)

SK-G300

Mechanical Station	Eight stations
Types of Packaging Bags	Stand-up bags, handbags, four-side sealing bags, three-side sealing bags, paper bags and other composite bags
Bag Size	W: 180-300mm L: 100-400mm
Packing Weight	10-2500g
Packing Speed	10-30 bags / min (the speed is determined by the feeding material itself and the filling weight)
Mechanical Weight	1700kg
Power Specifications	380V three-phase 50HZ / 60HZ
Total Power	3 KW
Compressed Air Consumption	0.8m3 / min (provided by the user)

Application

SK-G200

	Packaging Format Range	Adjustment Method	Packing Way	Packing Speed Range	Special Process
Puffed	10-50g	Display control	Multi-head Combination Scale	25-60 bags / min	None
Dried Fruits / Nuts	10-1000g	Display control	Multi-head Combination Scale	25-60 bags / min	None
Fertilizers	10-1000g	Display control	Linear scale	25-60 bags / min	None
Feed	10-1000g	Display control	Linear scale	25-60 bags / min	None
Frozen	10-1000g	Display control	Multi-head Combination Scale	25-60 bags / min	Multi-head scale with dimpled material
Grains	10-1000g	Display control	Multi-head Combination Scale	25-60 bags / min	None

SK-G260

	Packaging Format Range	Adjustment Method	Packing Way	Packing Speed Range	Special Process
Puffed	10-70g	Display control	Multi-head Combination Scale	25-50 bags / min	None
Dried Fruits / Nuts	10-1500g	Display control	Multi-head Combination Scale	25-50 bags / min	None
Fertilizers	10-1500g	Display control	Linear scale	25-50 bags / min	None
Feed	10-1500g	Display control	Linear scale	25-50 bags / min	None
Frozen	10-1500g	Display control	Multi-head Combination Scale	25-50bags / min	Multi-head scale with dimpled material
Grains	10-1500g	Display control	Multi-head Combination Scale	25-50bags / min	None

SK-G300

	Packaging Format Range	Adjustment Method	Packing Way	Packing Speed Range	Special Process
Puffed	10-100g	Display control	Multi-head Combination Scale	10-30bags / min	None
Dried Fruits / Nuts	10-2500g	Display control	Multi-head Combination Scale	10-30bags / min	None
Fertilizers	10-2500g	Display control	Linear scale	10-30bags / min	None
Feed	10-2500g	Display control	Linear scale	10-30bags / min	None
Frozen	10-2500g	Display control	Multi-head Combination Scale	10-30bags / min	Multi-head scale with dimpled material
Grains	10-2500g	Display control	Multi-head Combination Scale	10-30bags / min	None
