Automatic Powder & Liquid Packaging Machine
This type of packaging machine is a hot-selling packaging machine, which is used in many conventional bag size packaging in life. With different measurement methods, it can be used to package different types of products.
- PLC control, imported driver, imported touch screen, man-machine interface, high degree of automation, simple operation procedure, high sensitivity of touch screen.
- Fully automatic bag sealing, forming, and date printing.
- Machine packaging is fast, saving labor.
- Low cost by using roll film forming envelopes.
- Multiple language operating systems, suitable for different countries.
Parameter
| Air Consumption Consumption | 0.65mpa, 2.5m3 / min | ||||||
| Packaging Film Width | 220-520mm | ||||||
| Bag Style | Pillow bag | ||||||
| Bag Length | 80-350mm | ||||||
| Bag Width | 100-250 mm | ||||||
| Max Outer Diameter of Coil | Max.520mm | ||||||
| Packing Speed | 5-70bags / min | ||||||
| Packaging Film Thickness | 0.04-0.08mm | ||||||
| Power Specifications | 220V, 50Hz / 60Hz, 3kW | ||||||
| Packing Dimension (L*W*H) | (L)1430*(W)1200*(H)1700mm | ||||||
| Packaging Materials | Composite film | ||||||
| Total Power | 3KW | ||||||
| Overall Weight | 650kg | ||||||
Application
| Packaging Format Range | Adjustment Method | Packing Way | Packing Speed Range | Special Process | |
| Puffed | 25-120g | Display control | Multi-head combination scale weighing system | 30-50bags / min | Need to filling nitrogen |
| Dried Fruits / Nuts | 100-1500g | Display control | Multi-head combination scale weighing system | 30-50bags / min | Bag exhaust |
| Fertilizers | 100-1500g | Display control | Linear scale weighing system | 20-50bags / min | Bag exhaust |
| Feed | 100-1500g | Display control | Linear scale weighing system | 20-40bags / min | Bag exhaust |
| Frozen | 100-1500g | Display control | Multi-head combination scale weighing system | 20-50bags / min | Multi-head scale with dimpled surface |
| Grains | 100-1500g | Display control | Linear scale weighing system/Measuring cup | 20-40bags / min | Bag exhaust |
| Seeds | 100-1500g | Display control | Linear scale weighing system | 20-40bags / min | Bag exhaust |
