Vertical Granule/Powder Pouch Packaging Machine

This is a small and medium-sized vertical packaging machine, mainly for small bag packaging, servo control, stable operation, fast packaging speed, small size, and easy to operate. It is suitable for packing various granular/powder/liquid products.

This machine is small, low noise and economical.
PLC control, imported driver, imported touch screen, man-machine interface, high degree of automation, simple operation procedure, high sensitivity of touch screen.
The machine is easy to operate and maintain.
Unique film feeding design saves film materials and reduces costs.
Multiple language operating systems.

ADD TO CART

Product Details

Parameter

Air Consumption	0.65mpa, 2.5m3 / min
Packaging Film Width	120-380mm
Bag Style	Pillow bag
Bag Length	80-240mm
Bag Width	50-180mm
Max Outer Diameter of Coil	Max.300mm
Packing Speed	5-85bags / min
Packaging Film Thickness	0.04-0.08mm
Power Specifications	220V, 50Hz / 60Hz, 2.4kW
Packing Dimension (LWH)	(L)1200(W)820(H)1350mm
Packaging Materials	Composite film
Total Power	2.4KW
Overall Weight	350kg

Application

	Packaging Format Range	Adjustment Method	Packing Way	Packing Speed Range	Special Process
Puffed	20-35g	Display control	Multi-head Combination Scale / Measuring cup	30-60bags / min	Air filling
Dried Fruits / Nuts	20-100g	Display control	Multi-head Combination Scale / Measuring cup	20-60bags / min	Bag exhaust
Fertilizers	50-500g	Display control	Measuring cup	20-60bags / min	Open-closed door
Feed	50-500g	Display control	Measuring cup	20-60bags / min	Open-closed door
Grains	50-500g	Display control	Measuring cup / Linear scale	20-60bags / min	Bag exhaust
Hardware	1-20pcs	Display control	Counting Vibrating Disc	10-50bags / min	Customized Disc
